Honeywell V4055A1114 | OEM Certified On-Off Fluid Power Gas Valve Actuator

The Honeywell V4055A1114, part of the V4055A series of fluid power actuators, is a robust on-off actuator engineered for controlling gas supply valves in commercial and industrial burner systems. Paired with the Honeywell V5055 or V5097 gas valves, it is rated for final safety shut-off service. Process Solutions+2nexinstrument.com+2

Equipped with a maximum closing time of just one second, this actuator meets stringent safety and insurance requirements. The standard opening time is approximately 26 seconds at 60 Hz or 32 seconds at 50 Hz, although fast-opening models are available showing ~13 seconds at 60 Hz or ~16 seconds at 50 Hz.

Key Features:
• Engineered for on-off fluid power control of gas supply in burner systems.

• Extremely fast maximum closing time of 1 second when de-energised.

• Opening time options: ~26 s at 60 Hz (standard) or ~13 s (fast-opening) at 60 Hz.
• Ambient operating temperature range: approx. -40 °F to +150 °F (-40 °C to +66 °C) for 60 Hz models; for 50 Hz/50-60 Hz models: -10 °F to +158 °F (-23 °C to +70 °C).• Direct mounting onto valve bonnet (V5055/V5097 valves) via setscrews — actuator may be mounted in any orientation (with some exceptions for certain voltage/frequency models).
• Visual position indicators: red “OPEN” indicator when valve is open, yellow “SHUT” indicator when valve is fully closed.
• Available accessories including auxiliary switches, max-flow limit switch, damper shaft options, spring-return options, weather-proof (NEMA 4) enclosures.

Ideal for industrial burner systems, commercial heating installations, and gas-fired process equipment requiring reliable, rugged, and code-compliant actuator/valve combinations.
